相机制造商

传感器
产品型号 类型 彩色C/ 扫描类型 图像格式/分 工作波段 接口 帧率 数据率
Spectrum
Scan
辨率
Product Sensor 黑白M type Image format digitized Interface Frame/s Data rate
type
JAI San Jose, CA, USA; 408-383-0300; www.jai.com; camerasales.americas@jai.com
Camera Link, Camera Link Extended,
GO-5101 CMOS C+M Area array 2464 x 2056 NIR, VIS 22–35 —
GigE
Camera Link, Camera Link Extended,
GO-5000 CMOS C+M Area array 2560 x 2048 NIR, VIS ≤107 —
GigE, USB3
GO-5100 CMOS C+M Area array 2462 x 2056 NIR, VIS GigE, USB3 22–74 —
Camera Link, Camera Link Extended,
GO-2400 CMOS C+M Area array 1936 x 1216 NIR, VIS 48–165 —
GigE, USB3
GO-2401 CMOS C+M Area array 1936 x 1216 VIS GigE 41 —
AT-200 CCD C Area array 1620 x 1236 VIS Camera Link, Camera Link Full, GigE 15–20 —
Multispectral,
AD-130 CCD C+M Area array 1296 x 966 GigE 31 —
NIR, VIS
SW-4000M-PMCL CMOS M Linescan 3 x 4096 VIS Camera Link, Camera Link Full — 200 kHz
KEYENCE Corp of America Itasca, IL, USA; 888-539-3623; www.keyence.com/usa; keyence@keyence.com
CA-HX048C/M CMOS C+M Area array 784 x 596 VIS Proprietary ≤588 —
CA-HX200C/M CMOS C+M Area array 1600 x 1200 VIS Proprietary 86.2 —
CA-HX500C/M CMOS C+M Area array 2432 x 2040 VIS Proprietary 36 —
CA-H2100C/M CMOS C+M Area array 5104 x 4092 VIS Proprietary 9 —
CV-S035C/M CCD C+M Area array 640 x 480 VIS Proprietary 62.5 —
CV-S200C/M CCD C+M Area array 1600 x 1200 VIS Proprietary 17 —
XG-HL02M CMOS M Linescan 1 x 2048 VIS Proprietary — 41.7 kHz
XG-HL04M CMOS M Linescan 1 x 4096 VIS Proprietary — 41.7 kHz
XG-HL08M CMOS M Linescan 1 x 8192 VIS Proprietary — 22.2 kHz
Lumenera Corp Ottawa, ON, Canada; 613-736-4077; www.lumenera.com; info@lumenera.com
Lt1265R CCD C+M Area array 4240 x 2832 NIR, VIS USB3 15 5 Gbps
Lt365R CCD C+M Area array 1936 x 1456 NIR, VIS USB3 53 5 Gbps
Lt665R CCD C+M Area array 2752 x 2192 NIR, VIS USB3 27 5 Gbps
Lt965R CCD C+M Area array 3376 x 2704 NIR, VIS USB3 19 5 Gbps
Lt225 CMOS C+M Area array 2048 x 1088 NIR, VIS USB3 170 5 Gbps
Lt425 CCD C+M Area array 2048 x 2048 NIR, VIS USB3 90 5 Gbps
Lg11059 CCD C+M Area array 4008 x 2672 VIS GigE 5 1 Gbps
Lm11059 CCD C+M Area array 4008 x 2672 VIS USB 1.0/2.0, USB3 4.3 400 Mbps
Lm075 CCD C+M Area array 640 x 480 NIR, VIS USB 1.0/2.0, USB3 60 400 Mbps
Lm085 CMOS C+M Area array 752 x 480 NIR, VIS USB 1.0/2.0, USB3 60 420 Mbps
Lm135 CCD C+M Area array 1392 x 1040 NIR, VIS USB 1.0/2.0, USB3 15 480 Mbps
Lm165 CCD C+M Area array 1392 x 1040 NIR, VIS Ethernet, USB 1.0/2.0, USB3 15 480 Mbps
Lw135R CCD C+M Area array 1392 x 1040 NIR, VIS USB 1.0/2.0, USB3 30 480 Mbps
Lw165R CCD C+M Area array 1392 x 1040 NIR, VIS USB 1.0/2.0, USB3 30 480 Mbps
Lw235 CCD C+M Area array 1616 x 1216 NIR, VIS USB 1.0/2.0, USB3 12 480 Mbps
Lw565 CCD C+M Area array 2448 x 2048 NIR, VIS USB 1.0/2.0, USB3 8.5 480 Mbps
Lw115 CMOS C+M Area array 1280 x 1024 NIR, VIS USB 1.0/2.0, USB3 30 480 Mbps
Lw575 CMOS C+M Area array 2592 x 1944 NIR, VIS USB 1.0/2.0, USB3 7 480 Mbps
Lt16059H CCD C+M Area array 4864 x 3232 VIS USB 1.0/2.0, USB3 11 5 Gbps
Lt29059 CCD C+M Area array 6576 x 4384 VIS USB 1.0/2.0, USB3 6 5 Gbps
MATRIX VISION GmbH Oppenweiler, Germany; 49-7191-9432-0; www.matrix-vision.com; sales@matrix-vision.de
mvBlueSIRIUS CCD C+M Area array 1024 x 900 — Digital I/O, GigE 25 —
mvBlueGEMINI CMOS C+M Area array 1280 x 1024 VIS Digital I/O, Ethernet, RS-232 60 —
640 x 480– Digital I/O, Ethernet, RGB, RS-232,
mvBlueLYNX-X series — C+M Area array VIS 10–117 —
2448 x 2050 USB 1.0/2.0
