相机制造商

传感器
产品型号 类型 彩色C/ 扫描类型 图像格式/分 工作波段 接口 帧率 数据率
Scan
Spectrum
辨率
Product Sensor 黑白M type Image format digitized Interface Frame/s Data rate
type
XIMEA Münster, NRW, Germany; 49-251-202-408-0; www.ximea.com; info@ximea.com
xiQ - USB 3.0 CMOS CMOS C+M Area array 648 x 488 VIS USB3 500 480 Mbps
xiQ - USB 3.0 CMOS CMOS C+M Area array 1280 x 1024 NIR, VIS USB3 60 480 Mbps
xiQ - USB 3.0 CMOS CMOS C+M Area array 1280 x 1024 VIS Digital I/O, USB3 210 480 Mbps
xiQ - USB 3.0 CMOS CMOS C+M Area array 2048 x 1088 NIR, VIS Digital I/O, USB3 170 380 Mbps
xiQ - USB 3.0 CMOS CMOS C+M Area array 2048 x 2048 NIR, VIS USB3 90 380 Mbps
1940 x 1460,
2758 x 2208,
xiD - Scientific grade CCD C+M Area array NIR, VIS Digital I/O, USB3 60 480 Mbps
3380 x 2704,
4242 x 2830
12 Mpix PCIe cameras high speed CMOS C+M Area array 4096 x 3072 NIR, VIS Digital I/O, Fiberoptic, PCle 333 20 Gbps
xiB - 20 Mpix PCIe cameras high CMOS C+M Area array 5120 x 3840 VIS Digital I/O, PCle 33 20 Gbps
speed
Thunderbolt with Sony IMX174 CMOS C+M Area array 1936 x 1216 NIR, VIS Digital I/O, PCle, Proprietary, USB3 165 10 Gbps
Scientific grade CCD 4Mpix CCD C+M Area array 2048 x 2048 NIR, VIS Digital I/O, FireWire 5 98 MBps
NIR, X-ray,
Scientific grade CCD 11Mpix CCD C+M Area array 4032 x 2688 Digital I/O, FireWire 2 98 MBps
VIS
NIR, X-ray,
Scientific Grade CCD 16Mpix CCD C+M Area array 4904 x 3280 Digital I/O, FireWire 1.5 98 MBps
VIS
xiRAY - High resolution CCD C+M Area array 4904 x 3280 X-ray Digital I/O, FireWire 2 98 MBps
Board level cameras from 1 to CCD C+M Area array — NIR, VIS Digital I/O, Fiberoptic, FireWire, PCle, — 98 MBps
16 Mpix Proprietary, USB 1.0/2.0, USB3
北京嘉恒中自图像技术有限公司 北京市海淀区中关村东路95号自动化大厦10层; 010-51665596; www.jhi.com.cn; market@jhi.com.cn
640x480- 100-
OK_Analog Camera series CCD C+M Area array NIR,VIS Analog,Digital I/O,NTSC,PAL,RS-232 25-140
1300x1024 400Mbps
640x480- 400-
OK_LVDS Camera series CCD M Area array NIR,VIS Digital I/O,RS-232,RS-644 LVDS _
1300x1024 420Mbps
640x480- 400-
OK_CameraLink Camera series CCD C+M Area array NIR,VIS Camera Link,Digital I/O,RS-232 24-100
1300x1024 420Mbps
CCD, 1024x768-
OK_USB Camera series C+M Area array NIR,VIS Digital I/O,USB 1.0/2.0 _ 480Mbps
CMOS 2048x1536
640x408-
OK_GigE Camera series CCD C+M Area array NIR,VIS Digital I/O,GigE 25-100 1000Mbps
1360x1024
CCD, 1280x960-
OK_GigE Mini Camera series C+M Area array NIR,VIS Digital I/O,GigE 15-60 1000Mbps
CMOS 2456x2058
OK_LineScan Camera series CCD C+M Linescan 1024-3x2048 NIR,UV,VIS Camera Link,Digital I/O,GigE 7k-37k 1000Mbps
640x480-
OK_Smart Camera series CCD C+M Area array NIR,VIS Digital I/O,GigE 1-100 100Mbps
1600x1200
OK_Special Function Camera CCD M Area array 3056x3056- NIR,VIS Digital I/O,GigE,USB 1.0/2.0 0.2 480Mbps
series 4096x4096
北京凯视佳光电设备有限公司 北京市海淀区曙光花园望河园（观澜国际花园）3-2-801; 18910369478; www.catchbest.com; catchbest@foxmail.com
Jelly3 MU3C120M/C CMOS C+M Area array 1280×960 IR USB3 60 72MB/s
Jelly3 MU3E130M/C CMOS C+M Area array 1280×1024 IR USB3 60 78MB/s
Jelly3 MU3V130M/C CMOS C+M Area array 1280×1024 IR USB3 120 156MB/s
Jelly3 MU3E200M/C CMOS C+M Area array 1600×1200 IR USB3 60 120MB/s
Jelly3 MU3C500M/C CMOS C+M Area array 2592×1944 IR USB3 14 70MB/s
Jelly3 MU3C1001C CMOS C Area array 3856×2764 IR USB3 14 140MB/s
Jelly3 MU3C1401C CMOS C Area array 4608×3288 IR USB3 12 168MB/s
Elanus GC130M/C CMOS C+M Area array 1280×1024 IR GigE 60 78MB/s
Elanus GC200M/C CMOS C+M Area array 1600×1200 IR GigE 50 100MB/s
Elanus GC500M/C CMOS C+M Area array 2592×1944 IR GigE 14 70MB/s
MU3HS2000M/C CMOS C+M Area array 5472x3648 IR USB3 18 2880Mb
MU3HS500M/C CMOS C+M Area array 2464x2056 IR USB3 71 2840Mb
